AL600P "I GROOVE EDITION"

คุณสมบัติหลัก

MORE EFFICIENT AND ENVIRONMENTALLY FRIENDLY FINISHING OF THICK PLATE WORKPIECES.

- Wire Rotation Mechanism "i groove" -
Applying rotation to the wire during finishing reduces wire consumption and allows a new wire surface to be constantly used for finishing from the top to the bottom of the workpiece.
This is especially suited to finishing thick plate workpieces.
It offers innovative machining performance including stable machining dimensions, improvement of surface scoring, and reduced wire consumption.
- New groove and step machining function "Stepcut" -
It permits machining at the same speed as under standard conditions while significantly improving the accuracy and range of applications when machining shapes with rapidly changing material thickness, such as stepped shapes.

LATEST ELECTRICAL DISCHARGE TECHNOLOGY FOR RAPID AND ACCURATE MACHINING

Sodick has been working for many years to develop the world's best wire-cut electric discharge machines. The AL Series "i Groove Edition" offers flexible control from high peak currents for efficient rough machining to ultra-fine discharge pulses for micro finishing.
In addition, The Sodick linear motor drive is a non-contact system that eliminates the need for ball screws. It is maintenance-free and maintains its initial accuracy almost indefinitely, with no drop off in machine accuracy due to ball screw wear throughout the life of the machine (10 years or more).

HIGH PRECISION PREMIUM SPECIFICATION, PURSUING ULTIMATE ACCURACY

Sodick pursued ultra-high precision in the machining, assembly and adjustment of machinery. By adopting ultra-high precision roller guides, high rigidity was also achieved.
While standardly equipped with doors made of CFRP, the accuracy was thoroughly pursued in all factors originating in the machining accuracy to temperature control by a high quality inverter cooler.
