Supperdrilles Small hole EDM Sodick เครื่องเจาะรู

฿0.00

เครื่องเจาะรู แม่พิมพ์ขนาดเล็ก โซดิกส์ ซุปเปอร์ดิวส์

จำนวน

เหลือ 0 ชิ้น

รายละเอียดสินค้า Supperdrilles Small hole EDM Sodick เครื่องเจาะรู

Manuall High-speed small hole drilling EDM

K1C

The most reliable and the best selling
Small Hole Drilling EDM

Specifications

X,Y,Z axis stroke (mm)	200 × 300 × 300
Max. weight of workpiece (kg)	100
Table size (Width × Depth) (mm)	250 × 350
Machine tool dimensions (Width × Depth × Height) (mm)	810 × 870 × 2015

Main Features

User friendly design
An operation panel was placed on the front of the machine tool for an operator to work with it more comfortably. Display was placed in line with an operator’s eye level. Tool tray was installed in the front of the machine to put dies, electrodes, and etc.
The cutting edge servo technologies
Thanks to the latest servo technologies achieved through the know-how accumulated through the development of small hole drilling machines, axis response to the servo command has been greatly improved. Compared with the previous model, two times faster machining speed has been made possible.
Micro-step axis feed
Because axis feed is controlled with micro-level precision, stable and reliable machining is ensured.
Abundant machining conditions
To meet wide range of machining needs, abundant machining conditions have been prepared to cover the combination of various types of electrodes and workpiece.
